User Manual
Page 51
[2]SCHEDULE
The Schedule Tab is used to configure when the Alarm-Out function will be enabled.
DAY
Select day of a week for output selectable by ALL, MONDAY ~ SUNDAY, WEEKDAY
and WEEKEND.
START TIME Select start time for output.
END TIME Select end time for output.
MODE
Select mode among Event, On, and Off.
Event : On in case of Alarm or Motion
On : Always On, regardless of Event
Off: Always OFF, regardless of Event.
ALARM-OUT
OUT1: Mark checkbox to send signal to relay output terminal 1
OUT2: Mark checkbox to send signal to relay output terminal 2
