97
Setting the Parameters
Frequency
Level
Mix
Rate
HPF
eect range
Modulation
Depth
❺ FLANGER - RATE
Adjusts the modulation speed. It is linked with the [EFFECT AMOUNT] knob on the
top panel.
e setting range is 0 to 127. e cycle becomes faster as the value increases.
❻ FLANGER - DEPTH
Adjusts the depth of modulation.
e setting range is 0 to 127. e modulation becomes deeper as the value increases.
❼ FLANGER - RESONANCE
Adjusts the amount of resonance (feed-back).
e setting range is 0 to 127. e resonance becomes greater as the value increases. At
higher values, the sound is modulated beyond normal recognition.
❽ FLANGER - DELAY
Controls the delay of the eff ect sound.
e setting range is 0 to 127. e delay increases as the value is increased.
❾ FLANGER - MIX
Adjusts the volume balance between the “dry” and the eff ect sound.
e setting range is 0 to 127. At 0, only the “dry” is heard. e eff ect level becomes
greater as the value is increased. At 127 the ratio between the “dry” and the eff ect sounds
becomes 1:1.
❿ FLANGER - HPF
Controls the frequency range of the eff ect.
e setting range is 0 to 127. At 0 the eff ect is added to all frequencies. e eff ect is
added to the higher frequencies as the value increases.
Flanger
is is the sweeping “Jet Airplane” sound adjustable from a mild shimmer to a deep
“swoosh”.
❽
❹❺❻❼
❾❿
