Audio > Output > Mux
ADS Clean 7, 9 Enables the SDI embedder to
pre-clean the ancillary data space
• Yes
•No
SD-SDI Mux Bit Width 7, A Selects the audio mux bit width when
the signal is SD
•Yes
• No
Group Format Follow
Input
7, B Enables SDI embedding group format
follow input setting
•Yes
• No
SDI Group (1-4) Group
Mux Enable
7, C
•
7, F
Enables SDI embedding for audio
groups 1, 2, 3, and 4 when Group
Format Follow Input is disabled
• On
•Off
Audio > Output > Routing
Out Ch (1-L– 8-R) 6, 1
6, 2
6, 3
6, 4
6, 5
6, 6
6, 7
6, 8
7, 1
7, 2
7, 3
7, 4
7, 5
7, 6
7, 7
7, 8
Sets an audio source for the SD/HD
embedder
• In Ch1-L (Out Ch1-L)
• In Ch1-R (Out Ch1-R)
• In Ch2-L (Out Ch2-L)
• In Ch2-R (Out Ch2-R)
• In Ch3-L (Out Ch3-L)
• In Ch3-R (Out Ch3-R)
• In Ch4-L (Out Ch4-L)
• In Ch4-R (Out Ch4-R)
• In Ch5-L (Out Ch5-L)
• In Ch5-R (Out Ch5-R)
• In Ch6-L (Out Ch6-L)
• In Ch6-R (Out Ch6-R)
• In Ch7-L (Out Ch7-L)
• In Ch7-R (Out Ch7-R)
• In Ch8-L (Out Ch8-L)
• In Ch8-R (Out Ch8-R)
• Tone 1
• Tone 2
• Tone 3
• Tone 4
Tone (1-4) Level 8, 5
to
8, 8
Adjusts the audio gain of the specified
tone
-28 to 0 dBFS (-18)
Table 8-2. ACO6800+ISCST SDI Parameters (Continued)
Group Parameter Name
Bank,
Switch
Function Options
