ACO6800+ Installation and Operation Manual 93
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Audio > Processing > Delay
Delay Lock 8, 1 Sets whether you can adjust the audio
delay separately or for all channels
Note When this parameter is set to
Yes, Delay All is available, and you can
adjust the Delay All parameter to change
the delay for all 16 audio channels at the
same time. When it is set to No, the
Delay (1-8) parameters are available,
and you can adjust the delay of each
audio channel separately.
•Yes
• No
Delay All 8, 2 Sets the audio delay for all channels
when Delay Lock is enabled
0 to 2500 ms (0)
Delay 1 (Ch1-L) and
Delay 2 (Ch1-R) to
Delay 15 (Ch.8-L) and
Delay 16 (Ch8-R)
Adjusts the audio delay for each
channel when Delay Lock is disabled
0 to 2500 ms (0)
Audio > Processing > Gain
Gain Lock 8, 3 Sets the audio gain separately or for
all channels
•Yes
• No
Gain All 8, 4 Adjusts the audio gain for all channels
when Gain Lock is enabled
-18 dB to 18 dB (0)
Gain 1 (Ch1-L) and
Gain 2 (Ch1-R) to
Gain 15 (Ch.8-L) and
Gain 16 (Ch8-R)
Adjusts the audio gain for each
channel when Gain Lock is disabled
Note The gain control is disabled when
the SRC is set to Bypass.
-18 dB to 18 dB (0)
Audio > Processing > Phase Invert
Invert All 6, E Inverts the audio phase for all
channels
•On
• Off
Invert 1 (Ch1-L) and
Invert 2 (Ch1-R) to
Invert 15 (Ch.8-L) and
Invert 16 (Ch8-R)
Inverts the audio phase for each
channel when Gain Lock is disabled
Note The inverter is disabled when the
SRC is bypassed.
•On
• Off
Audio > Processing > Audio Processing Bit Width
Ch (1-8) Processing Bit
Width
Specifies the internal processing bit
width of the audio
• 24 bit (Default when
operational standard is
HD)
• 20 bit (Default when
operational standard is
SD)
• 16 bit
Table 8-2. ACO6800+ISCST SDI Parameters (Continued)
Group Parameter Name
Bank,
Switch
Function Options
