92 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Audio
LOV Mute En 6, 9 Mutes the audio as soon as the video is
lost
• Enable
• Disable
Fade Time 6, A Adjusts the global fade rate for audio
gain
0.01 s to 10s (2)
Master Mute 6, B Mutes audio on all output channels
•Enable
• Disable
V-bit Mute 6,C Mutes audio when V bit is set
•Enable
• Disable
Audio >Input > Demux Status
Ch (1-8) Audio Type
[RO]
Reports the audio presence and type
•N/A
•PCM Audio
•Data
Audio > Input > Demux Setting
SDI Group Err Ctrl Sets the audio output behavior when
the audio has an error
• Repeat
• Mute
SDI DBN Error Control Sets the reporting behavior when the
audio has a DBN error
• Alert
• Ignore
SDI Group Error Status Reports group errors for SDI audio
•On
•Off
SDI DBN Error Status Reports DBN errors for SDI audio
•On
•Of
Audio > Processing > SRC Bypass
SRC Bypass Mode 6, D Sets the SRC control mode
Note When this parameter is set to
Auto, the module automatically
bypasses SRCs when a Dolby package
is detected. When it is set to Manual,
you can manually change the SRC (1-8)
Bypass parameters.
• Auto
• Manual
SRC (1-8) Bypass Enables bypass for the specified SRC
when SRC Bypass Mode is set to
Manual
•Yes
• No
Table 8-2. ACO6800+ISCST SDI Parameters (Continued)
Group Parameter Name
Bank,
Switch
Function Options
