ACO6800+ Installation and Operation Manual 91
Copyright © 2009, Harris Corporation
Chapter 8: ACO6800+ISCST Parameters, LEDs, and Alarms
Cr Offset 5, 6 Sets the video Cr offset 0 to 100% (50%)
Hue Phase 5, 7 Sets the hue for color
Note Range depends on the set
operation standard: -90 to 90 only @
SD-625.
• -180 to 180 degrees (0)
• -90 to 90 degrees (0)
White Clip Enable 5, 8 Activates the white clip
•Enable
• Disable
White Clip Level 5, 9 Sets the white clip level
Note Units depend on the set
operation frame rate: IRE @ 59.94 or
mV @ 50.
• 90.1 to 109.0 IRE (100)
• 636.8 to 763.2 mV (700)
Black Clip Enable 5, A Activates the black clip
•Enable
• Disable
Black Clip Level 5, B Sets the black clip level
Note Units depend on the set
operation frame rate: IRE @ 59.94 ore
mV @ 50.
• -6.8 to 6.8 IRE (0)
• -47.9 to 47.9 mV (0)
Video > Out 1_2 Settings
OSD Enable 5, C Activates the on-screen display on
outputs 1 and 2
•On
• Off
EDH 5, D Activates the EDH insert after frame
synchronizer
Note Only available when the
operation standard is 525 or 625.
• Insert
• Clear
Video > AUX Settings
AUX Output Source 1, F Sets the backup channel’s output
source
Note When Frame Sync is selected,
the source is the output of the
synchronizer.
When AUX is selected, the source is
always the different input from one
selected into the synchronizer.
• Frame Sync
• AUX
•IN 1
•IN 2
AUX OSD Enable 5, E Activates the on-screen display on
AUX outputs
•On
• Off
AUX EDH 5, F Activates the EDH insert on AUX
Note This parameter is only available
when selected input for AUX is 525 or
625.
• Insert
• Clear
Table 8-2. ACO6800+ISCST SDI Parameters (Continued)
Group Parameter Name
Bank,
Switch
Function Options
