82 ACO6800+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 7: ACO6800+ASID Parameters, LEDs, and Alarms
PID error Referred PID does not occur for the selected
repetition rate
42 5
Transport error Transport error indicator in the Transport
Stream Header is set to 1 *
22 5
CRC error A CRC error has occurred in the selected table.
The individual table CRC alarm(s) must be
enabled on the parameters page. The CRC error
alarms include:
PAT, PMT, CAT, NIT (DVB), BAT (DVB),
SDT (DVB), EIT (DVB), TOT (DVB), MGT
(ATSC), TVCT (ATSC),
CVCT (ATSC), RRT (ATSC),
EIT (ATSC), ETT (ATSC),
STT (ATSC).
22 5
PCR error Reports one or both of the following:
• A PCR discontinuity of more than the
selected period
• Time interval between two consecutive PCR
values more than the selected repetition
period. (spec 40 ms) *
The PCR Accuracy Repetition rate and
Discontinuity rate adjustments are on the
ETR-290/Priority 2 Alarms page on the
Parameters tab. The PCR PID alarm(s) must
also be must be enabled on the ETR-290/
Priority 2 Alarms page.
22 5
PCR accuracy error Reports that the PCR accuracy of selected
program is more than the selected period for the
PID(s) selected. The PCR Accuracy threshold
adjustment is on the ETR-290/Priority 2 Alarms
page on the Parameters tab. The PCR PID
alarm(s) must also be must be enabled on the
ETR-290/ Priority 2 Alarms page.
22
5
Table 7-6. ACO6800+ASID Subdevice Alarms
Alarm Name Alarm Description
Alarm Option Default Settings
Alarm
priority
Trigger (s) Clear (s)
