360179-A/B 13
Installation & Conguration
3 Attach the at bracket to the bottom front of the cart.
a Hand-thread one (1) thumb screw and tighten.
Attach at bracket to cart
4 Roll the cart next to the Compartmental Access Refrigerator.
5 Attach the two (2) L brackets to the Compartmental Access Refrigerator.
a Hand-thread one (1) screw through the L bracket into the threaded hole in the Compartmental
Access Refrigerator.
b Using a #2 Phillips screwdriver, tighten the screw.
Attach L bracket to Compartmental Access Refrigerator
6 Attach the at bracket to the Compartmental Access Refrigerator.
a Hand-thread one (1) thumb screw and tighten.
Attach at bracket to Compartmental Access Refrigerator
