Maintenance & Service
10 Service
10.1 Refrigerant Charge
NOTICE Use only non-CFC R-134A refrigerant.
Full initial refrigerant charge varies by model and power requirements, which can be found on the product
specication label.
Model
Power
Requirements
Initial Charge Design Pressures
iBX080 115 V, 60 Hz,
230 V, 50/60 Hz
10.1 oz. (286 g) low 88 psig
high 186 psig
10.2 Replace Chamber LED Lamp Strip
CAUTION Switch the AC ON/OFF switch OFF when replacing the lamp strip.
NOTE Contact Haemonetics
®
Corporation BloodTrack
®
Customer Support for replacement LED
lamp strip. Order Service Kit Part number 800023-1.
Required tools:
► #2 Phillips screwdriver
Replace the lamp strip:
1 Switch the AC ON/OFF switch OFF.
2 Using a # 2 Phillips screwdriver, detach lamp strip from chamber.
3 Unsnap the defective lamp strip and disconnect wires.
4 Connect new lamp strip to the wires.
5 Reattach lamp strip to chamber.
6 Switch the AC ON/OFF switch ON.
