Helmer iBX080 - Access Console Problems

360179-A/B 54
Troubleshooting
Problem Possible Cause Action
Bypass Release
handle and lock do
not release.
Lock is engaged
► Ensure correct key has been inserted and is in the
unlock position.
Bypass Release
handle is broken
► Replace handle.
LED indicator lamp
does not illuminate to
indicate which tray is
unlocked.
IRACS board is not
functioning properly
► Contact Haemonetics

Corporation BloodTrack

Customer Support.
Multiple LED indicator
lamps illuminate to
indicate multiple trays
are unlocked.
IRACS board is not
functioning properly
► Contact Haemonetics

Corporation BloodTrack

Customer Support.
Unlocked trays can be
completely removed.
Tray bumper is not
installed
► Install the tray bumper.
Non-factory tray
bumper is installed
► Install a factory-supplied tray bumper.
Incorrect compartment
unlocks.
VIB is not set correctly
or is faulty
► Check that each row shows a unique address
(Refer to Section IV, Item 11.1.6)
- If not, check and set rotary switch on each
VIB accordingly and then cycle refrigerator AC
and battery power. Topmost VIB rotary switch is
position 0; second from top VIB rotary is position
1; third from top VIB rotary switch is position 2;
bottom VIB rotary switch is position 3.
► Contact Haemonetics

Corporation BloodTrack

Customer Support.
11.11 Access Console Problems
Problem Possible Cause Action
Speaker is not
audible.
Audible sounds
are not functioning
properly on the
BloodTrack
®
kiosk
► Conrm speaker connections are secure at P1 on
amplier board and at speaker.
► Conrm 12V DC at P2 on amplier board.
► Conrm audio jack on LINE OUT of ACCESS
CONSOLE DISPLAY.
► Replace speaker and amplier if necessary.
► Contact Haemonetics

Corporation BloodTrack

Customer Support.
