10.3.2 Replace Tray Bumpers
NOTE ► Refer to Section III, Part 10.3 for instructions in removing the tray from the
compartment assembly.
► Only use tray bumpers supplied with the Compartmental Access Refrigerator. The
use of non-Compartmental Access Refrigerator tray bumpers may allow the tray to be
removed without following the proper protocols of the BloodTrack
®
system.
► Contact Haemonetics
®
Corporation BloodTrack
®
Customer support for replacement
bumpers. Part number 800267-1.
Remove a tray bumper:
1 Remove the tray from the compartment location. (Refer to Section III, Item 10.3.1).
2 Slide the rubber tray bumper toward the side of the Compartmental Access Refrigerator.
3 Lift the tray bumper upward to disengage it from the keyhole in the bottom of the compartment
location.
4 Discard the tray bumper.
Install a tray bumper:
1 Insert the post on the new rubber tray bumper through the wide end of the keyhole in the bottom of
the compartment location.
2 Slide the tray bumper to the narrow end of the keyhole.
3 Grip the tray bumper and pull it upward to ensure it is installed correctly.
► The tray bumper should not be able to be removed
► If the tray bumper can be removed by pulling it upward, ensure it is toward the small hole of the
keyhole
4 Reinstall the tray in the compartment location.
