12.4 Compartment Access Components
A B C D
Compartment access components.
Label Description
Part Number /
Service Kit Number
A Compartment control PCB assembly 800222-1
B Power distribution board 800257-1
C 24V DC power supply 800213-1
D Router 800260-1
Not
Shown
Spare IRACS board with solenoids
(under compartment cover)
800262-1
