Helmer iBX080 - Replace the Chart Recorder Backup Battery; Check Probe Bottle; Check Probe Bottle Solution; Inspect and Replace Probe Bottle

360179-A/B 31
Maintenance & Service
9.3.6 Replace the Chart Recorder Backup Battery
NOTE A replacement battery is available from Haemonetics
®
Corporation BloodTrack
®
Customer
Support. Order Part number 120218
Replace the battery:
1 Open the chart recorder door by pressing and releasing the door.
2 Remove the battery from the battery holder.
3 Disconnect the power leads to the battery.
4 Connect the power leads to the new battery.
5 Install the new battery in the battery holder.
6 Close the chart recorder door by pressing and releasing the door.
9.4 Check Probe Bottle
9.4.1 Check Probe Bottle Solution
Check solution:
1 Visually inspect the contents of the upper chamber probe bottle.
► Probe(s) should be immersed at least 2” (50 mm) in solution
► If solution is low, clean and rell the probe bottle
9.4.2 Inspect and Replace Probe Bottle
NOTE ► A kit that includes a probe bottle and glycerin is available from Haemonetics

Corporation BloodTrack

Customer Support. Order Service Kit Part number 400922-1 .
NOTICE Temperature probes are fragile; handle with care.
Required supplies:
► 4 oz. probe bottle
► 4 oz. (120 mL) of product simulation solution per bottle
► 10:1 ratio of water to glycerin
Inspect probe bottle:
1 Visually inspect the probe bottle for cleanliness, discoloration, and damage.
► If probe bottle is damaged, replace the probe bottle and solution
► If probe bottle is dirty, clean the bottle and rell the solution as outlined in Section III, Item 9.6.7
Replace probe bottle:
1 Remove probe(s) from bottle.
2 Remove bottle from bracket.
3 Discard the bottle and solution.
4 Fill new bottle with 4 oz. (120 mL) of product simulation solution.
5 Cap bottle tightly to minimize evaporation.
6 Place bottle in bracket.
7 Replace probe(s), immersing at least 2” (50 mm).
