HGM COMPUSHIFT II - Page 108

COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 108
CONNECT
OR
RO
W
PIN # PIN NAME FUNCTION WIRE
COLOR
TERMINATIO
N
NOTES
TRANS 1 A 11 SOLENOID 5 SS2
CONTROL
SIDE
BLU/YEL TRANS PLUG
PIN 7
TRANS 1 A 12 SOLENOID 6 SS1
CONTROL
SIDE
YEL/BLU TRANS PLUG
PIN 6
TRANS 1 B 1 GND MLPS GND BLK 4 WAY PIN D WEATHERPAC
K 4PIN
TRANS 1 B 2 GND NO
CONNECTIO
N
TRANS 1 B 3 TOSS OUTPUT
REPRO
REPRO TOSS PPL/WHT OUT OF LOOM
@ TOSS
FLYING LEAD
TRANS 1 B 4 TEMP SENSOR
RET
TRANS TEMP BRN TRANS PLUG
PIN 4
TRANS 1 B 5 TISS INPUT
LOW
NO
CONNECTIO
N
TRANS 1 B 6 TOSS INPUT
LOW
TOSS LOW PPL TOSS PIN B WEATHERPAC
K 2PIN FEM
TRANS 1 B 7 DIGITAL SHIFT
LEVER 1
RANGE
SENSOR A
BLU/RED 4 WAY PIN A WEATHERPAC
K 4PIN
TRANS 1 B 8 DIGITAL SHIFT
LEVER 2
RANGE
SENSOR B
BLU/BLK 4 WAY PIN B WEATHERPAC
K 4PIN
TRANS 1 B 9 DIGITAL SHIFT
LEVER 3
RANGE
SENSOR C
BLU 4 WAY PIN C WEATHERPAC
K 4PIN
