Specifications & Pinouts– 118
CONNECT
OR
RO
W
PIN PIN NAME FUNCTION WIRE
COLOR
TERMINATION NOTE
S
ENGINE B 3 MODE MODE A/B SWITCH BLUE/OR FLYING LEAD
ENGINE B 4 MODE SWITCH SWITCH LED ON/
OFF
FLYING LEAD
ENGINE B 5 OD ON/OFF LED TO LED ON
SWITCH
BLU/RED FLYING LEAD
ENGINE B 6 OD CANCEL
SWITCH
SWITCH INPUT TO
ECM
BLU/YEL FLYING LEAD
ENGINE B 7 SWITCH SHIFT
UP
SHIFT UP WHT/RED FLYING LEAD
ENGINE B 8 SWITCH SHIFT
COM
GND OR COMMON WHT/RED FLYING LEAD
ENGINE B 9 SWITCH DOWN SHIFT DOWN WHT/BLK FLYING LEAD
ENGINE B 10 ENGINE TEMP
RETURN
ENGINE B 11 CAN1 - CAN BUS LOW
SIGNAL
ENGINE B 12 GND
8.6.4.3 OPTIONS Connector
A 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
B 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
