COMPUSHIFT II Manual – COMPUSHIFT II Manual
Unpacking & Inspecting Your Kit– 18
2.4 Power & Engine Wiring Harness
The Power & Engine Wiring Harness, shown here (or one similar) connects the COMPUSHIFT II Controller to the
vehicle's TPS, tachometer, speedometer and power.
Seehere for installation instructions(see page 25).
Each harness has a rubber grommet for the firewall. These are placed in a recommended spot, but can
be repositioned.
2.5 Hydraulic Pressure Sensor Harness (Optional)
The Hydraulic Pressure Sensor Harness, shown here, connects the COMPUSHIFT II Controller to the transmission's
hydraulic pressure sensor port.
