8.6.1 Pinouts for Engine Connector
8.6.1.1 ENGINE Connector
A 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
B 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
Note: This is the view into the receptacle on controller, not the plug.
CONNECT
OR
RO
W
PIN PIN NAME FUNCTION WIRE
COLOR
TERMINATION NOTE
S
ENGINE A 1 TACH SIG IN INPUT RPM SIG BRN FLYING LEAD
ENGINE A 2
ENGINE A 3
ENGINE A 4 5V TPS 5 VOLT
SUPPLY
GRN/RED TPS TERMINAL
C
ENGINE A 5 TPS SIGNAL TPS SIGNAL GRN TPS TERMINAL
B
ENGINE A 6 TPS RETURN TPS GND GRN/WHT TPS TERMINAL
A
ENGINE A 7 5V
ENGINE A 8 MAP SIGNAL
