Specifications & Pinouts– 135
8.6.7 Pinouts for Ford E4OD
8.6.7.1 TRANS 1 Connector
A 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
B 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
Note: This is the view into the receptacle on controller, not the plug.
CONNECT
OR
RO
W
PIN PIN NAME FUNCTION WIRE
COLOR
TERMINATIO
N
NOTES
TRANS 1 A 1 +12V POWER 12VDC
SOLENOIDS
RED 18GA TRANS PLUG
PIN 1
TRANS 1 A 2 +12V POWER 12VDC PRES
SOL
RED/BLK
18GA
TRANS PLUG
PIN 12
TRANS 1 A 3 +5V POWER 5VDC TO 1K
RES
B7 PULL UP RES
TRANS 1 A 4 TEMP SENSOR TRANS TEMP BRN TRANS PLUG
PIN 7
TRANS 1 A 5 TISS INPUT
HIGH
NO
CONNECTION
TRANS 1 A 6 TOSS INPUT
HIGH
TOSS HIGH PPL/YEL TOSS PIN A WEATHERPAC
K 2PIN FEM
TRANS 1 A 7 SOLENOID 1 PRESS SOL
CONT
GRN/RED TRANS PLUG
PIN 11
TRANS 1 A 8 SOLENOID 2 TCC CONTROL
SIDE
GRN/WHT TRANS PLUG
PIN 4
