HGM COMPUSHIFT II User Manual

COMPUSHIFT II Manual – COMPUSHIFT II Manual
Installation– 28
•
•
•
•
•
•
•
•
3.4.1.1 Find the AccuLink TPS Parts
You should have the following parts:
Sensor bracket
Ratio arm
Adjustable arm (2 pieces)
Two 10/32" x 7/8" Phillips pan-head screws
Other mounting hardware (stainless steel nuts, washers, brackets and screws)
3.4.1.2 Assemble the AccuLink TPS and Bracket
Identify the TPS itself, the sensor bracket and the two 10/32" x 7/8" Phillips pan-head screws.
Mount the TPS to the sensor bracket with the screws gently tightened. Be sure the plug side of the TPS is
vertical (near the bracket mount), as shown.
Tighten the TPS screws.
Sorry, the widget is not supported in this export.
But you can reach it using the following URL:
http://www.youtube.com/watch?v=dL7vZdjkIos
