COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 117
CONNECT
OR
RO
W
PIN PIN NAME FUNCTION WIRE
COLOR
TERMINATION NOTE
S
ENGINE A 1 TACH SIG IN INPUT RPM SIG BRN FLYING LEAD
ENGINE A 2
ENGINE A 3
ENGINE A 4 5V TPS 5 VOLT
SUPPLY
GRN/RED TPS TERMINAL
C
ENGINE A 5 TPS SIGNAL TPS SIGNAL GRN TPS TERMINAL
B
ENGINE A 6 TPS RETURN TPS GND GRN/WHT TPS TERMINAL
A
ENGINE A 7 5V
ENGINE A 8 MAP SIGNAL
ENGINE A 9 MAP RETURN
ENGINE A 10 ENGINE TEMP
ENGINE A 11 CAN1 + CAN BUS HIGH
SIGNAL
YEL
ENGINE A 12 12V RED
ENGINE B 1 TOSS OUT
REPRO
ADJUSTABLE
SPEEDOMETER
OUTPUT
PPL/WHT FLYING LEAD
ENGINE B 2
