HGM COMPUSHIFT II User Manual

COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 112
CONNEC
TOR
RO
W
PI
N
NAME FUNCTION WIRE
COLOR
TERMINATI
ON
NOTES
OPTIONS A 3 CAN2+ CAN BUS 2
HIGH SIGNAL
OPTIONS A 4 RS232 TX DISPLAY RED DISPLAY
PLUG
OPTIONS A 5 LIN DATA COMMUNICATI
ON
OPTIONS A 6 NO
CONNECTION
OPTIONS A 7 NO
CONNECTION
OPTIONS A 8 NO
CONNECTION
OPTIONS A 9 SOLENOID 12 REVERSE
LAMP RELAY
Must drive relay,
not lamps directly.
OPTIONS A 10 SOLENOID 11 NEUTRAL
START RELAY
Not available on
GM 4L80E, GM
4L60E, GM 4L65E
OPTIONS A 11 SOLENOID 10
OPTIONS A 12 SOLENOID 9
OPTIONS B 1 GND GND
OPTIONS B 2 GND GND DISPLAY BLACK DISPLAY
PLUG

HGM COMPUSHIFT II Specifications

General

Brand	HGM
Model	COMPUSHIFT II
Category	Controller
Language	English
