COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 129
CONNECT
OR
RO
W
PI
N
NAME FUNCTION WIRE
COLOR
TERMINATIO
N
NOTES
TRANS 1 A 8 SOLENOID 2 TCC CONTROL
SIDE
GRN/WHT TRANS PLUG
PIN 3
TRANS 1 A 9 SOLENOID 3 NO
CONNECTION
TRANS 1 A 10 SOLENOID 4 NO
CONNECTION
TRANS 1 A 11 SOLENOID 5 SS 2-3
CONTROL SIDE
BLU/YEL TRANS PLUG
PIN 5
TRANS 1 A 12 SOLENOID 6 SS 1-2
CONTROL SIDE
YEL/BLU TRANS PLUG
PIN 1
TRANS 1 B 1 GND MLPS GND BLACK MLPS PIN B WEATHERPAC
K 2PIN MALE
TRANS 1 B 2 GND NO
CONNECTION
TRANS 1 B 3 TOSS OUTPUT
REPRO
REPRO TOSS PPL/WHT OUT OF LOOM
@ TOSS
FLYING LEAD
TRANS 1 B 4 TEMP SENSOR
RET
TRANS TEMP BRN TRANS PLUG
PIN 8
TRANS 1 B 5 TISS INPUT
LOW
NO
CONNECTION
TRANS 1 B 6 TOSS INPUT
LOW
TOSS LOW PPL TOSS PIN B WEATHERPAC
K 2PIN FEM
TRANS 1 B 7 DIGITAL SHIFT
LEVER 1
MLPS BLU/RED MLPS PIN A WEATHERPAC
K 2PIN MALE
To Next Page
