COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 143
CONNECT
OR
RO
W
PIN PIN NAME FUNCTION WIRE
COLOR
TERMINATIO
N
NOTES
TRANS 1 A 9 SOLENOID 3 TCC 4L80E GRN/WHT TRANS PLUG
PIN S
TRANS 1 A 10 SOLENOID 4 TCC 4L60E GRN TRANS PLUG
PIN T
TRANS 1 A 11 SOLENOID 5 SS 2-3
CONTROL SIDE
BLU/YEL TRANS PLUG
PIN B
TRANS 1 A 12 SOLENOID 6 SS 1-2
CONTROL SIDE
YEL/BLU TRANS PLUG
PIN A
TRANS 1 B 1 GND NO
CONNECTION
TRANS 1 B 2 GND NO
CONNECTION
TRANS 1 B 3 TOSS OUTPUT
REPRO
REPRO TOSS PPL/WHT OUT OF LOOM
@ TOSS
FLYING LEAD
TRANS 1 B 4 TEMP SENSOR
RET
TRANS TEMP
LOW
BRN TRANS PLUG
PIN M
TRANS 1 B 5 TISS INPUT
LOW
NO
CONNECTION
TRANS 1 B 6 TOSS INPUT
LOW
TOSS LOW PPL TOSS PIN B WEATHERPA
CK 2PIN
TRANS 1 B 7 DIGITAL SHIFT
LEVER 1
PSM A BLU/RED TRANS PLUG
PIN N
TRANS 1 B 8 DIGITAL SHIFT
LEVER 2
PCM B BLU/BLK TRANS PLUG
PIN R
