Education Sharing System User Manual
58
Chapter 10 Network Settings
Basic Network Settings
Go to Configuration > System Settings > Network Settings > TCP/IP.
Basic Network Settings
Select Working Mode as Net Fault-Tolerance, Load Balance, or Multi-Address.
Net-fault Tolerance Mode: The two NIC cards use the same IP address, and you can select the
Main NIC to any LAN. By this way, in case of one NIC card failure, the system will automatically
enable the standby NIC card so as to ensure the normal running of the whole system.
Load Balance: By using the same IP address and two NIC cards share the load of the total
bandwidth, which enables the system to provide two Gigabit network capacity.
Multi-address Mode: The parameters of the two NIC cards can be configured independently.
You can select a LAN in the NIC type field for parameter settings. You can select one NIC card
as the default route. And then the system is connecting with the extranet the data will be
forwarded through the default route.
Set the NIC settings.
1) Select NIC Type.
