User Manual of Digital Video Recorder
100
the screen.
Figure 6. 12 Draw Area for Smart Search
4. Click-and-drag the mouse to draw area(s) for smart search of VCA event or motion event.
Traversing Virtual Plane Detection
Click the button , and then click on the video display screen to specify the start point and end point of
the virtual plane.
Intrusion Detection
Click the button, and then specify 4 points to set a quadrilateral region for intrusion detection. Only one
region can be set.
Motion Detection
Click the button and then click-and-draw the mouse to set the detection area manually. You can also
click the button to set the full screen as the detection area.
Smart search of VCA events is only supported by smart IP cameras connected to the HDVR series.
5. Click the button to set the playback rule.
Skip the Non-Related Video: The non-related video will not be played if this function is enabled.
Play Non-Related Video at: Set the speed to play the non-related video. Max./8/4/1 are selectable.
Play Related Video at: Set the speed to play the related video. Max./8/4/1 are selectable.
Pre-play and post-play is not available for the motion event type.
6. Click the to search, and then the result will be displayed as in the progress bar of the Smart
Playback interface.
