User Manual of Digital Video Recorder
103
Figure 6. 16 Interface of Playback by Log
6.1.6 Playing Back External Files
Purpose:
The record files stored in the external storage devices, e.g., USB flash drives, USB HDDs, can be searched and
played back.
Before you start:
Insert the external device(s) with available record files into the device.
Steps:
1. Enter the Playback interface.
Menu > Playback
2. Select External File from the drop-down list in the upper-left corner of the page to enter the External File
Playback interface.
The files stored in the extrenal device are listed in the right-side list.
You can click the Refresh button to refresh the file list.
3. Select a record file and click to play it.
