User Manual of Digital Video Recorder
131
8.1 Setting Motion Detection
We use the interface of DS-9100HFI-ST series (unless otherwise stated) as example to describe the following
settings.
Steps:
1. Enter Motion Detection interface and choose a camera you want to set motion detection.
Menu> Camera> Motion
2. Set detection area and sensitivity.
Check checkbox to enable motion detection, use the mouse to draw detection area(s) and drag the
sensitivity bar to set sensitivity.
Figure 8. 1 Set Detection Area and Sensitivity
3. Click to configure the motion detection settings. Click Trigger Channel tab and select one or more
channels which will start to record/capture or become full-screen monitoring when motion alarm is triggered.
Click Apply to save the settings.
Figure 8. 2 Set Trigger Camera of Motion Detection
Triggering IP Camera is supported by HDVR series only.
4. Set arming schedule of the channel.
Select Arming Schedule tab and set arming schedule of the channel.
Choose one day of a week and up to eight time periods can be set within each day. Set up arming schedule of
other days of a week. You can also click the button Copy to copy an arming schedule to other days. Click
Apply to save the settings.
Time periods cannot be repeated or overlapped.
