User Manual of Digital Video Recorder
77
5.5 Configuring VCA Recording and Capture
Purpose:
Follow the procedure to configure VCA event triggered recording or capture.
The VCA settings and VCA event triggered recording / capture are supported by the analog cameras 01~04
or the smart IP cameras connected to the HDVR only.
Steps:
1. Enter the VCA settings interface and select a camera for the VCA settings.
Menu> Camera> VCA
Figure 5. 19 VCA Settings-Analog Camera
Figure 5. 20 VCA Settings-IP Camera
2. Configure the detection rules for VCA events. For details, see the step 2 in Chapter 8.5 Detecting VCA
Alarm.
3. Click the icon to configure the alarm linkage actions for the VCA events.
Select Trigger Channel tab and select one or more channels which will start to record/capture when VCA
alarm is triggered. Click Apply to save the settings
