User Manual of Digital Video Recorder
133
8.2 Setting Sensor Alarm
Purpose:
You can set handling method of an external sensor alarm.
Sensor alarm is not supported by DS-7200HWI-SV series.
Steps:
1. Enter Alarm Settings interface and select an alarm input.
Menu> Configuration> Alarm
Figure 8. 5 Alarm Status Interface
2. Select Alarm Input tab to enter Alarm Input Settings interface, edit the name for the alarm input and set the
handling method of the selected alarm input.
Check checkbox to enable the alarm input and click to configure the alarm settings..
Figure 8. 6 Alarm Input Settings Interface
3. Select Trigger Channel tab and select one or more channels which will start to record/capture or become
full-screen monitoring when an external alarm is input. Click Apply to save the settings.
4. Select Arming Schedule tab to set the channel’s arming schedule.
Choose one day of a week and up to eight time periods can be set within each day. Set up arming schedule of
other days of a week. You can also click Copy to copy an arming schedule to other days. Click Apply to
save the settings.
