User Manual of Digital V
ideo Recorder
24
1.4
Input Method Descrip
tion
Figure 1. 4
So
ft Keyboard (1
)
Figure 1. 5
So
ft Keyboard (2)
Description of the buttons on the soft key
b
oard:
Table 1. 5
Descrip
tion of the Soft Ke
yboard Icons
Icon
Description
Icon
Description
…
Number
…
English letter
Lowercase/Uppercase
Backspace
Switch the keyboard
Space
Positioning the cursor
Exit
Symbols
Reserved
24
