User Manual of Digital V
ideo Recorder
80
Figure 5. 23
Conti
nuous Capture
IP Camera
is supported by
HDVR
series only.
2)
Click the status button before camera number to change
to
to
enable continuous capture.
3)
Or click the status button to change
to
to disable continuous capture.
After rebooting, all the continuous capture will be canceled.
