User Manual of Digital Video Recorder
94
interface.
3. Check checkbox of channel(s) in the channel list.
4. Double-click to select a date on the calendar to play back the record file.
If there are normal recordings (manual or schedule) for that camera in that day, on the calendar, the
icon for that day is displayed as ; If there are event triggered recordings (motion, alarm, motion |
alarm, motion & alarm VCA) for that camera in that day, in the calendar, the icon for that day is
displayed as ; Otherwise it is displayed as .
The event triggered recordings will be displayed prior to the normal recordings on the calendar when
both the two types of recordings are available in that day.
Figure 6. 3 Playback Calendar
In the Playback interface:
The toolbar in the bottom part of Playback interface can be used to control playing process.
Figure 6. 4 Interface of Playback by Time
