130
────────────────────────────────────────────────────
9.2 Print Method
────────────────────────────────────────────────────
Measuring
range (Ω)
Measurement sampling rate
FAST MEDIUM, SLOW
300 m
□□□．□_mohm □□□．□□mohm
3
□．□□□__ohm □．□□□□_ohm
30
□□．□□__ohm □□．□□□_ohm
300
□□□．□__ohm □□□．□□_ohm
3k
□．□□□_kohm □．□□□□kohm
30 k
□□．□□□kohm
300 k
□□□．□□kohm
NOTE
Resistance measurement value
When displaying the deviation, "□□□,□□_%__" is printed.
When displaying the temperature conversion, "(mark)□□□, □_C" is printed.
When the over flow is generated, "OF", and when NG is generated, "NG" are
printed.
Comparator result
Print "Hi", "IN", or "Lo" according to the comparison result of the comparator.
The temperature measurement value: "(mark)□□,□□_C"
When the comparator is not used, no comparator result is printed.
