Chapter 4 Basic Operations 27
4.1 Operating Procedure 27
4.1.1 Function Classes 27
4.1.2 Key Shift States
28
4.1.3 Key Lock State
28
4.1.4 Remote State
28
4.1.5 Valid Input Key Table
29
4.2 Selecting the Measurement Mode 30
4.3 Resistance Measurement Mode 31
4.3.1 Selecting the Sampling Rate 31
4.3.2 Selecting the Measuring Range
32
4.3.3 Zero Adjustment
34
4.4 Resistance Measurement 35
4.5 Temperature Measurement
36
4.6 Holding the Measurement Value
37
Chapter 5 Applied Operations 39
5.1 Setting the Comparator 39
5.1.1 Setting the Comparator 1 39
5.1.2 Setting the Comparator 2
41
5.1.3 Eliminating the Comparator Table
42
5.2 Executing the Comparator 43
5.3 Setting the Temperature Correction
44
5.4 Executing the Temperature Correction
45
5.5 Setting the Temperature Conversion 46
5.6 Executing the Temperature Conversion 47
Chapter 6 External Control Terminals 49
6.1 Connector 49
6.1.1 Terminal Block 49
6.1.2 Digital I/O
50
6.2 Connecting Method 51
6.2.1 Terminal Block 51
6.2.2 Digital I/O
51
6.3 Electrical Specifications 53
6.3.1 Power Supply Rating 53
6.3.2 Input and Output Rating
53
6.3.3 Input and Output States
54
