77
_____________________________________________________________________________________________
7.4 Command Reference
______________________________________________________________________________________________
Syntax
[:SENSe:]VOLTage[:DC]:RANGe data
[:SENSe:]VOLTage:AC:RANGe data
[:SENSe:]CURRent:DC:RANGe data
[:SENSe:]CURRent:AC:RANGe data
[:SENSe:]RESistance:RANGe data
[:SENSe:]LPResistance:RANGe data
[:SENSe:]FRESistance:RANGe data
[:SENSe:]LPFResistance:RANGe data
[:SENSe:]CLAMp:DC:RANGe data
[:SENSe:]CLAMp:AC:RANGe data
[:SENSe:]FREQuency:VOLTage:RANGe data
data
NRf numerical data
Input the expected measurement value. The unit automatically selects the optimum range for
measuring the given entered value.
Function
Sets a range for the selected measurement function.
Note
Any attempt to set a range outside measurement range for the specified measurement function
will result in an execution error.
In the case of the frequency measurement function, the range set is for input voltages (attenuator
range), not frequencies.
Example
Transmission :SENS:VOLT:DC:RANGe -300
Sets the DC voltage measurement function to the 1000 V range.
RES:RANG 800
Sets the resistance measurement function to the 2000 Ω range.
:SENS:FREQ:VOLT:RANG 1.5
Sets the attenuator range to the 2 V range in a frequency measurement.
Syntax
[:SENSe:]VOLTage[:DC]:RANGe?
[:SENSe:]VOLTage:AC:RANGe?
[:SENSe:]CURRent:DC:RANGe?
[:SENSe:]CURRent:AC:RANGe?
[:SENSe:]RESistance:RANGe?
[:SENSe:]LPResistance:RANGe?
[:SENSe:]FRESistance:RANGe?
[:SENSe:]LPFResistance:RANGe?
[:SENSe:]CLAMp:DC:RANGe?
[:SENSe:]CLAMp:AC:RANGe?
[:SENSe:]FREQuency:VOLTage:RANGe?
data
NR3 numerical data
Function
Inquires about the range of the specified measurement function.
Response
syntax
Headers: ON :SENSE:LPRESISTANCE:RANGE data
Headers: OFF data
Example
Headers: ON
Transmission CURR:AC:RANG?
Response :SENSE:CURRENT:AC:RANGE 199.999E-03
Headers: OFF
Transmission CURR:AC:RANG?
Response 199.999E-03
The AC current measurement range is 200 mA.
Range setup
Inquiry concerning range
