105
Additional Function
Setting backup Yes
Stopping the measurement
Function overview Stopping the measurement.
Function setting By pressing START/STOP key during measurement, measurement stops.
Indicating measurement status
Function overview Indicating measurement in operation on the screen.
Function operation Indicating measurement in operation on the LCD screen when the measurement time is
long (about 1 s or more).
Panel saving and loading
Function overview Saves and reads measurement conditions.
Adaptive conditions Measurement function, Measurement range, Impedance measurement speed, Voltage
measurement speed, Measurement frequency, Comparator setting, Zero adjustment
setting, Zero adjustment data, Sample delay setting, Average, Trigger source setting, Self
calibration setting, Measurement signal zero cross stop setting, Slope correction setting,
Voltage limit
Numbers of panel 126
Function setting Save Saving current measurement conditions
Load Reading saved measurement conditions
Clear Erases saved measurement conditions
Detailed display Displays saved measurement conditions (displays adaptive
conditions)
Setting backup Yes (Backs up panel data)
Detecting the measurement error
Function overview Indicating measurement error, and performs error indication and error output.
Stopping measurement immediately after detection.
Malfunction detection
contents
Detected contents Detection timing Indication
Measurement current error
• Between trigger acceptance
and voltage measurement
• Between sampling delay
and measurement signal
zero cross stop
----
Contact error between
SOURCE-H and SENSE-H
Before and after
measurement
CONTACT ERR H
Contact error between
SOURCE-L and SENSE-L
Before and after
measurement
CONTACT ERR L
Voltage drift of the measuring object
During impedance
measurement
VOLTAGE DRIFT
Over-voltage input error When voltage is measured OVER VOLTAGE
Voltage limit error When voltage is measured OVER V LIMIT
Return cable unconnected error
After impedance
measurement
RETURN CABLE
ERROR
Detection timing
Refer to “8.2 Timing Chart” (p. 84)
Measurement error
display
Refer to “Error display and remedy” (p. 121)
10
Specications
