Additional Function
Comparator
Function overview Comparison functions of measurement and reference values
Function setting ON/OFF (Setting each measurement parameter)
Adaptive
measurement
Impedance measurement, voltage measurement
Setting the range for
upper and lower limit
values
Z: 0.0000 m
Ω
to 120.0000 m
Ω
θ
: -180.000° to 180.000°
R: -3.0000 m
Ω
to 120.0000 m
Ω
X: -120.0000 m
Ω
to 120.0000 m
Ω
V: -5.10000 V to 5.10000 V
Buzzer mode OFF/Hi • Lo/IN/ALL
Buzzer operation OFF No buzzer sound
Hi • Lo Short buzzer sound (three times)
IN Long buzzer sound
ALL In the case of Hi • Lo: Short buzzer sound
(three times)
In the case of IN Long buzzer sound
V absolute value
judgment
ON/OFF
Judgment result Hi/IN/Lo (impedance and voltage are independently judged)
PASS/FAIL judgment AND-operates the results of impedance judgment and voltage judgment, and then
outputs PASS/FAIL (EXT.I/O output)
Judgment operation
Measurement Result
Judgment
result
Output of EXT. I/O
Hi IN Lo ERR PASS FAIL
Hi Set value < Measured value Hi ON OFF OFF OFF OFF ON
Lo Set value ≤ Measured value ≤
Hi Set value
IN OFF ON OFF OFF ON OFF
Measured value < Lo Set value Lo OFF OFF ON OFF OFF ON
OverRange Hi ON OFF OFF OFF OFF ON
Measurement Error
Will not
judge
OFF OFF OFF ON OFF OFF
During interruption of
measurement
Will not
judge
OFF OFF OFF OFF OFF OFF
Setting backup Yes
Zero adjustment
Function overview Removing the residual components caused from offset and the measurement environment.
Adaptive
measurement
Impedance measurement, voltage measurement
Function setting ON/OFF
Adjustment mode SPOT/ALL
SPOT:
Zero adjustments are performed for the frequency and voltage measurements within the
range that is currently set.
ALL:
Zero adjustment is performed for all the frequencies and voltage measurements within the
range that is currently set.
