Additional Function
Zero adjustment range R -0.1000 m
Ω
to 0.1000 m
Ω
(3 m
Ω
range)
-0.3000 m
Ω
to 0.3000 m
Ω
(10 m
Ω
range)
-3.000 m
Ω
to 3.000 m
Ω
(100 m
Ω
range)
X -1.5000 m
Ω
to 1.5000 m
Ω
(Common for all ranges)
V -0.10000 V to 0.10000 V
Setting backup Yes
Self-Calibration
Function overview Calibration of internal circuit to maintain accuracy of voltage measurement.
Function setting AUTO/MANUAL
Execution timing AUTO Always performed every voltage measurements.
MANUAL Executed with EXT.I/O or command.
(Executed in the TRIG waiting state. The EXT. I/O or command will be
executed after the completion of measurement if a signal is received when
the measurement is in progress.)
Self-Calibration time 210 ms
Setting backup Yes
Sample delay
Function overview When the impedance measurement is performed, sets the number of waves to wait from
applying AC to sampling start. (p. 38)
Function setting WAVE/
∆
VOLT
WAVE: Sampling is performed only for the set wavenumbers after the application of
measurement signal.
Set with 0 wave to 9 wave (Resolution 0.1 wave, default value: 1 wave)
∆VOLT: Sampling is performed after the deviation of the measurement signal slope
drops below the set voltage.
Setting with 0.001 mV to 10.000 mV
Setting backup Yes
Average (Only for impedance measurement)
Function overview Averaging specied times of impedance measurement values and then output.
Function setting 1 to 99 times
Averaging method Simple average
R
A
R
nk
kn A
nA
avg( )
()
=
= − +
∑
1
11
Setting backup Yes
Slope correction of impedance measurements
Function overview Compensating the slope of AC signal when the impedance measurement is performed.
(p. 43)
Function setting ON/OFF
Setting backup Yes
