Hioki BT4560 - Page 46

40
Starting the Measurement After the Response of the Measuring Object is Stable (Sample Delay Function)
When selecting [WAVE], set the wavenumber of delay. (0.0 waves to 9.0 waves)
Setting
Conrm
(or)
Cancel
Move to the next digit
(left or right)
Changing the numerical
value (up and down)
When selecting [∆VOLT], set the voltage. (00.001 mV to 10.000 mV)
Setting
Conrm
(or)
Cancel
Move to the next digit
(left or right)
Changing the numerical
value (up and down)
