Redundancy
182
8.5
VRRP/HiVRRP
RM Web L3P
Release
4.1
03/08
Figure 71: Tracking dialog
Deleting a tracking object
In the Redundancy:VRRP:Tracking dialog, select a row and click
“Delete”. You thus delete the row.
Parameter Meaning
Port Port to which this entry applies, in the form <Slot>.<Port>
VRID Virtual router ID of the assigned virtual router.
TrackId ID number of the tracking object.
Decrement Value by which the current VRRP priority of the assigned VRRP
priority is reduced when the tracking object gets the status “down”.
Status Current status of the tracking object:
“up” or “down”.
Active Entry is displayed as “active” if the tracking object is completely set up
and is activated.
If the entry is active, you can find more information about it in the
„Tracking dialog“(see on page 180).
If the entry is not active, its status is always “up”.
Table 40: VRRP tracking table
