5. SPECIFICATION
5-6
(9) Maximum current specifications (USB port, Extension board, DisplayPort)
The following table shows the maximum total current consumption for the USB ports,
extension slots (PCI Express / PCI) and DisplayPort.
Table 5-9 Maximum current specifications
DC Output
Maximum total current consumption for
USB port 8 ports/
Extension board 7 slots/
DisplayPort 1 port
3.3V
8.0A
5V
8.0A
12V
8.0A
－12V
0.2A
The following table shows the maximum current consumption for each of the USB ports,
extension slots (PCI Express / PCI) and DisplayPort. Make sure that the inrush current
when a device is connected does not exceed the specified maximum current. If the inrush
current exceeds the specified maximum current, the surge protection circuit may be
activated and the connected device may not be recognized.
Table 5-10 Maximum current specifications by function
Item
Voltage
Maximum current
USB2.0/1.1 port
5V
0.5A/port
USB3.0/2.0/1.1 port
5V
0.9A/port
PCI Express x16 slot
(Connector shape is x16)
3.3V
3.0A/slot
12V
5.5A/slot
PCI Express x4 slot
(Connector shape is x8) (*1)
3.3V
3.0A/slot
12V
2.1A/slot
PCI Express x4 slot
(Connector shape is x4)
3.3V
3.0A/slot
12V
2.1A/slot
PCI Express x1 slot
(Connector shape is x4)
3.3V
3.0A/slot
12V
2.1A/slot
PCI slot
3.3V
6.0A/slot
5V
5.0A/slot
12V
0.5A/slot
-12V
0.1A/slot
DisplayPort
3.3V
0.5A/port
(*1) This slot cannot be used because the RAID board is installed.
