(3) Physical configuration inside the equipment
Figure 1-3 Physical Configuration Inside Equipment
Front fan 1
(installed inside the equipment)
Motherboard
Power supply unit
DVD drive
Drive bay 2
Drive bay 1
PS fan
Front fan 2
(installed inside the equipment)
