Hitachi TM3000 - Page 113

3 - 5
3.3 PC
Figures 3.3-1 and 3.3-2 show the components of the notebook PC. Note that the location of
the USB port may differ depending on the PC.
Figure 3.3-1 PC (Front View)
Figure 3.3-2 PC (Back View)
LCD monitor
Mouse
Notebook PC
(Main unit)
USB2.0 port
