4 - 93
1c. From the entry mode selection button, select the data to be entered (characters and
graphics) to enter data.
Figure 4.3.31-5 Data Entry/Measurement Window
NOTE
: Entered data (characters and graphics), once it is saved, cannot be re-edited.
To change data, before it is saved, delete it by pressing the Clear button and
re-enter it. Any deleted data cannot be recovered.
If a given specimen is observed under the same magnification, values obtained
from a quick measurement may vary due to differences in specimen height
(differences in focal positions). Also, size measurements can yield different results
between the center and the edges of the image.
NOTE
: Image files are created under conditions that are pre-selected on the Setting for
Save Window. By setting selected conditions and performing data entry and
measurement, images that match intended conditions can be saved.
Table 4.3.31 Image Types and Image Save Sizes
Image Type Image Save Size
Image only 640x480 pixels
Image + information 640x520 pixels
Image + information + comments 640x550 pixels
Saved images can be checked by using Explorer. Clicking the [F9] key on the keyboard
displays the folder in which the images are saved.
