6.3. Safe-Clean Station Function, Operation and Details of Control on

Screen

6.3.1. Operation of Safe-Clean Station Function

Press Setting on the [HOME] screen.

Press Next on the [Setting] screen.

Press Safe clean station function on the [Setting] (1/ 3) screen.
