Page #183 background imageLoading...
Page #183 background image
159
8.2.3. When performing high-speed printing by 4 lines. (Nozzle diameter: 65μm)
Necessary conditions for high-speed printing
● When all necessary conditions from Nos. 1 to 7 are satisfied, high-speed print HM, NM, QM or SM mode
can be selected.
No.
Item
Conditions
1
Print line
Print line of all columns is the 4.
2
Character size
Character size of all print items is the same.
(Refer to Table in "Type of high-speed print and number of vertical dots
used" for character sizes available.)
3
Line spacing
Line spacing of all columns is the same. However, if Line spacing is set to 3
or more, High-speed printing is NOT available.
4
Barcode
NOT available.
5
Character orientation
0 to 3.
6
Ink drop use rate
1/2
7
Ink drop charge rule
Standard (Single scan or interlaced)
Type of high-speed print and number of vertical dots used
● Number of vertical dots used in high-speed print is shown in Table below.
● When calculating printing preparation time, etc., pay attention to number of vertical dots.
Number of vertical dots used in the nozzle diameter is 65μm.
Ink drop use rate
1/1
1/2
-
HM
NM
QM
SM
D1
4-line print
Character size 5x5
20
40
-
-
36
-
Character size 5x7
28
56
-
-
50
-
Character size 5x8
32
64
-
-
58
-
