Hitachi UX2 Technical Manual

150
8.1.4. Precautions for use of DM code
● Set as shown below for print item to which DM is to be set:
(i) Number of lines : 1 line
(ii) Character size : 5×8, 12×16, 18×24
● Set barcode type on the print format screen.
Type of DM size and Maximum number of characters
Character size
5x8
12x16
18x24
DM size
8x32
14x14
16x16
16x36
16x48
18x18
20x20
22x22
24x24
No. of vertical dots
*1
8
14
16
16
16
18
20
22
24
Maximum
number of
characters
Numbers only
20
16
24
64
98
36
44
60
72
Alphabetical
characters only
10
8
12
32
49
18
22
30
36
Combination of
numbers,
alphabetical
characters and
symbols
10-19
8-15
12-23
32-63
49-97
18-35
22-43
30-59
36-71
Uppercase
alphabet
13
10
16
-
-
-
-
-
-
Lowercase
alphabet
13
10
16
-
-
-
-
-
-
(The number of characters that can be coded differs according to the numbers/characters string.)
(*1) Use the number of vertical dots provided in the table for speed calculation.
[Type of Encoding]
IJ printer automatically judges the character string which is input and executes the encoding as follow:
[1] When the number of digits of characters which are input is less than or that of Maximum number of
characters (Alphabet only), ASCII Encoding is executed.
[2] If the number of digits exceeds Maximum number of characters (Alphabet only), C40 Encoding or Text
Encoding is executed.
[Rules for calculating number of digits]
[1] In case that Alphanumeric and Symbols are mixed. (ASCII Encoding)
Alphabetical characters and symbols are treated as one digit per character.
Single independent numbers are treated as one digit per number.
In the case of consecutive numbers, two numbers are treated as one digit.
If a single number is left over, it is treated as one digit.
The total is within 12 digits for 16×16 and within 10 digits for 8×32.
(Example 1) Basic calculation rule
A B C 1 2 3 4 5 D 6 E
Total 9 digits
3 characters
= 3 digits
1 digit
1 digit
1 digit
3 characters
= 3 digits
