143
■
3 Remove the Slide stopper from Slide base, then remove the Cleaning Station.
■
4 Brush around Nozzle port by toothbrush with solvent.
■
5 Reverse the procedure above to reassemble the cleaning station unit in its original position.
NOTE
●There is possibility to drip solvent from nozzle port.
Slide Stopper
Slide Base
A
A arrow view
Cleaning Nozzle
Nozzle port
