- TI: HTI pair
HTI, SI, SIz, TC, TCz, UR, URz, and GAD volume status:
- Primary: P-VOL
- Secondary: S-VOL
FCv2 and FCSE volume status (VSP G1000, G1500, and VSP F1500):
- S-Normal: The source volume in the normal status. S means a
source volume.
- T-Normal: The target volume in the normal status. T means a
target volume.
- ST-Normal: The normal volume which is set for the source volume
and the target volume.
- S-Failed, S-Full, S-Full & Failed: The source volume in the
abnormal status.
- T-Failed, T-Full, T-Full & Failed: The target volume in the
abnormal status.
- ST-Failed, ST-Full, ST-full & Failed: The abnormal volume which
is set for the source volume and the target volume.
If you have not configured a pair, a hyphen (-) is displayed.
4. (Optional) To download table information to a file, click Export.
Related tasks
•
Changing system options that affect Thin Image performance on page 121
• Viewing local replication summary information on page 157
•
Viewing Thin Image pair task history on page 167
Related references
• Replication window on page 226
Viewing local replication summary information
You can view summary local replication information, such as the number of
pairs for each software application you are using, in the summary section of
the Local Replication window.
Procedure
1. In the Explorer pane, click Storage Systems, expand the storage
system tree, expand Replication, and then click Local Replication.
2. In the summary section of the Local Replication window, view the
following information:
Number of Pairs
The number of pairs for each local replication software application
type. The total number of pairs is shown on the Total line.
Default: ShadowImage, ShadowImage for Mainframe, and Thin
Number of Consistency Groups
Monitoring and maintaining Thin Image 157
Hitachi Thin Image User Guide for Hitachi Virtual Storage Platform G Series and F Series
