Item Description
Licensed Capacity The used and licensed capacity of each software
application.
Number of Replica LDEVs The number of LDEVs used for replication.
Number of FCv2/FCSE Relationships
(VSP G1000, G1500, and VSP F1500)
The number of FCv2 and FCSE relationships that are
in use.
Number of Differential Tables The number of differential tables in use and the
differential table limit, for local replication.
Differential tables in use for remote replication are
not included.
Because differential tables are not used for all
operations, the number of differential tables does
not change when you execute the following
operations:
• Thin Image pair operations.
• SIz pair operations for a DP-VOL that exceeds
262,668 cylinders.
• SI pair operations for a DP-VOL that exceeds 4
TB.
• Compatible FlashCopy
®
V2 or Hitachi Compatible
FlashCopy
®
relationship operations.
View History > Local Replication Click to open the View History window for local
replication.
View History > Remote Replication Click to open the View History window for remote
replication.
Edit Options > Local Replication Click to open the Edit Local Replica Options
wizard.
Edit Options > Remote Replication Click to open the Edit Remote Replica Options
wizard.
For more information about using this wizard to set
the number of volumes, path blockade, and other
options, see the Hitachi TrueCopy® User Guide.
Edit Options > SCP Time
(VSP G1000, G1500, and VSP F1500)
Click to open the Edit SCP Time wizard.
For more information about the tasks you can
perform using this wizard, see the Hitachi
TrueCopy® User Guide.
Replica LDEVs tab
This tab shows only pairs that consist of the P-VOL and S-VOLs (the source
and target volumes for FCv2 or FCSE) allocated to each user.
The following table lists the items on the Replica LDEVs tab.
Item
Description
LDEV ID The selected LDEV's identification number, which is a combination
of the LDKC, CU and LDEV. Click the ID to open the LDEV
Properties window, from which you can view the properties
assigned to the selected LDEV.
Thin Image GUI windows and wizards 227
Hitachi Thin Image User Guide for Hitachi Virtual Storage Platform G Series and F Series
